Shallow foundations are those that transfer load to the soil at a depth close to the lowest floor of the building.
Foundations are generally the lowest part of building walls. They may be made of stone, concrete, or steel.
The foundation aims to support the building and transmit its weight, both live and dead, to the subsoil without failing as long as the building lasts.
A good foundation should not:
- break under a load
- be destroyed by the roots of trees
- be affected by the presence of water
The building regulation states that the foundation must:
- Safely transfer all dead, imposed, and wind loads to the ground without settlement or other movement that would impact the stability or cause damage to the building itself or any adjoining building.
- Be taken down below the frost-damage or soil-movement level.
- Be resistant to attacks by sulfate or other deleterious matters found in the soil.
Designing foundations for medium-sized structures—such as 3- to 5-story apartment buildings, small warehouses, or commercial offices—requires a balance between cost efficiency and structural safety.
Shallow foundations are the preferred choice when the soil at a shallow depth has sufficient bearing capacity to support the load without excessive settlement.
